Sapphire Pro V1 3D Printer (Partially Assembled)

0104110000077509

New product

Main features:

  • Easy to assemble (about 30 minutes for complete installation)
  • MKS open-source robin NANO motherboard, 3.5 inch touch screen
  • Print size 235 x 235 x 235 mm
  • Support multi-language interface operation
  • Double ring cooling
  • Power-off continuous function
  • Automatic leveling module is not included! The motherboard supports auto leveling but the module must be bought separately.


See description for more details about the product.

Add to cart now!

More details

This product is no longer in stock

$287.76
tax incl.

Valid in the limit of the available stock

The price includes the costs for collection, treatment and ellimination of WEEE

Add to wishlist

More info

Specifications

  • Model: Sapphire Pro
  • Colour: Black
  • Machine material: Sheet metal
  • Number of nozzles: 1
  • Nozzle diameter: 0.4 mm
  • Hot bed size: 235 x 235 mm
  • Max print size: L235 x W235 x H235 mm
  • Print size: L220 x W220 x H220 mm
  • Print accuracy: 0.05 mm
  • Layer thickness: 0.1 - 0.4 mm
  • Printing method: TF card / online printing (PC)
  • Display: 3.5" color touch screen
  • Machine speed: max 1000 mm/s
  • Printing speed: max 300 mm/s
  • Extrusion head temperature (max): 260oC
  • Hot bed maximum temperature (max): 100oC
  • Print material: PLA, ABS, PETG, wooden filament
  • Filament diameter: 1.75 mm
  • Operating language: EN, RU, ES, FR, IT, ZH-CN, ZH-HK
  • Software format: STL, OBJ, JPG
  • Print file format: Gcode
  • Machine size: L405 x W380 x H466 mm
  • Package size: L500 x W430 x H250 mm
  • Machine weight: 11.5 Kg
  • Package weight: 14 Kg
  • Power parameter: 220 V/110 V 360W
  • Operating system: Windows, MAC
  • Support software: Cura, 3DPrinterOS, Repetier-Host and other slicing software
  • Working environment: Temperature: 5-40oC, Humidity: 20-60% RH
  • XY axis positioning accuracy: 0.01 mm
  • Z axis positioning accuracy: 0.0025 mm


Below you can find an animated video that shows how the main parts are mounted:


In the Download section you can find the installation manual for the 3D printer, but you can follow the next video tutorial that shows the main steps you can follow to fully assemble the printer:


Don't delay. Buy today.


Add to cart now!

Reviews

Grade
06/21/2021

Imprimanta CoreXY cu un raport pret-calitate excelent

Aceasta varianta V1 reprezinta o versiune mult imbunatatita in urma recenziilor variantei initiale. Calitatea mecanica este foarte buna (inclusiv ambalarea impresioneaza), fiind relativ usor de montat iar calitatea printurilor este foarte buna chiar cu hotendul si tubul bowden original (am testat initial doar cu ABS, rola de test ce vine in pachet).
Este silentioneaza (avand drivere TMC2208 pe axele X Y) dar intretimp am inlocuit cu acest model si driverele A4988 de pe axa Z si Extruder (iar acum nu se mai aude nici cand retracteaza filamentul).
Desi imprimanta functioneaza bine cu componentele originale, structura de calitate constituie o baza excelenta pentru upgrade-uri (inclusiv inchiderea simpla cu un enclosure similar variantei V2 pentru utilizare ABS, managementul cablurilor fiind foarte bun/avantajos).
Trebuie acordata putina atentie 'reglajelor' la montare. Axele de ghidare D12, de otel ale axei Z au avut lungimea cu tolerenta pe plus (in cazul meu, putin superioara inaltimii coloanelor profil 20) ceea ce poate conduce la torsionarea nedorita a cadrului plan superior, cu efect negativ asupra geometriei ghidajelor liniare ale axei Y. Solutia rapida a fost adaugarea unor plat-saibe distantiere de 0,5 mm grosime sub placa cadru superioara si coloanele profil 20. De asemenea, curelele axei X si Y trebuie bine intinse si folosite orificiile interioare (mai mici) pentru introducerea curelei, cele mari fiind destinate fixarii bridelor de plastic; astfel se evita reducerea nedorita a cursei de lucru pe axa X si functionarea incorecta a limitatorului de home/minim al axei X.
