> >11p Bent Female XH2.54 Connector
11p Bent Female XH2.54 Connector View larger

Imaginile sunt utilizate exclusiv cu titlu de prezentare. Fotografiile nu creează obligații contractuale.

11p Bent Female XH2.54 Connector

0104210000057003

New product

11p Bent Female XH2.54 Connector

More details

7 Items

$0.14
tax incl.

Valid in the limit of the available stock

The price includes the costs for collection, treatment and ellimination of WEEE

Add to wishlist

More info


Specification

• Pitch: 2.5mm

• Poles: 2 ~ 16

• Useable wire range: AWG30# ~ 22#

• Applicable printed board thickness: 0.8 ~ 1.6mm

• Voltage rating: 250v AC/DC

• Current rating: 3A AC/DC

• Working temperature: -25°c ~ +85°c

• Withstand voltage: 1000v/min

• Contact resistance: ⩽0.02

• Insulation resistance: ≥1000mΩ

• Housing: Nylon66


Pin header

• Water: Nylon66

• Pin: Brass

• Terminal: Phosphor bronze




Poles Part No. 2.5mm Dimensions (mm)
A B C
2 YX-XH-2 2.5 7.5 1
3 YX-XH-3 5 10 3.5
4 YX-XH-4 7.5 12.5 6
5 YX-XH-5 10 15 8.5
6 YX-XH-6 12.5 17.5 11
7 YX-XH-7 15 20 13.5
8 YX-XH-8 17.5 22.5 16
9 YX-XH-9 20 25 18.5
10 YX-XH-10 22.5 27.5 21
11 YX-XH-11 25 30 23.56
12 YX-XH-12 27.5 32.5 26
13 YX-XH-13 30 35 28.5
14 YX-XH-14 32.5 37.5 31
15 YX-XH-15 35 4 33.5
16 YX-XH-16 37.5 42.5 36
