Product Details

Seeeduino Cloud is a microcontroller board based on Dragino WiFi IoT module HE and ATmega32u4. HE is a high performance, low cost 150M, 2.4G WiFi module which means "core" in Chinese and with an Open Source OpenWrt system inside. Seeeduino Cloud is also an Arduino compatible board, 100% compatible with Grove, shield and IDEs(Arduino IDE 1.5.3 and later). Except for the normal interface of Arduino, Seeeduino Cloud has built-in Ethernet and WiFi support, a USB-A port which makes it very suitable for those prototype design that needs network connection and mass storage. It is also a good idea to make Seeeduino Cloud to an IoT gateway.


Features

  • Compatible with Arduino Yun
  • Based on Dragino WiFi IoT module HE
  • Open Source OpenWrt system inside
  • Support 2.4Ghz WiFi, 802.11 b/g/n
  • Support Ethernet
  • Support USB 2.0
  • Size: 75.10mm x 53.39mm x 11.50mm / 2.95"x 2.10 x 0.45"
  • Working temperature: -20~60oC
  • Surface color: Red


Technical Details

Dimensions 116mm x 76mm x 26mm
Weight G.W 54g
Battery Exclude
HE Module
CPU ATHEROS AR9331
Clock Speed 400MHz
RAM 64MB
Flash 16MB
OS Open Source OpenWrt
Interfaces 2 x RJ45, 1 x USB Host, 1 x UART, 14 multiplex GPIOs
Power 3.3V power input
WiFi Support 150M 2.4Ghz WiFi, 802.11 b/g/n
AVR Arduino Microcontroller
Microcontroller ATmega32u4
Flash Memory 32KB
SRAM 2.5kB
EEPROM 1kB
Clock Speed 16MHz
Digital I/O Pins 20
PWM Channels 7
Analog Input Channels 12

Part List

Seeeduino Cloud 1
Antenna 1
