Quanum Elite X40-L 25mW TX Transmitter with Metal Case

Description

The Quanum Elite X40-2 Transmitter delivers 5.8GHz 25mW without interruption, making it ideal for First Person View (FPV) projects. This is one of the best transmitters if you need a large coverage range. It can transmit on 40 channels and has a selection system very easy to use.

The Elite X40-2 quanum comes in an aluminum case that is not only resistant to shocks or other dangers but also uses heat dissipation. The housing also provides gripping holes, so you can secure the module for more safety.

Technical specifications

• Offers built-in microphone
• Very light: 12.5g
• Channels: 40 ch
• Aluminum housing
• Button to change band and channels
• Vertical Antenna
• Output impedance: 50 Ohm
• Frequency: 5645-5945 Mhz
• Supply voltage: 7 - 20V
• Current: 70mA
• Output voltage: 5V
• Operating temperature: -10^oC ~ 85^oC
• Audio Frequency: 6.5 Mhz
• Weight: 12.2g
• Antenna connector: SMA mother
• Dimensions: 32 x 24 x 9.4mm

Compatible with fractions

FRA: 5740MHz, 5760MHz, 5780MHz, 5800MHz, 5820MHz, 5840MHz, 5860MHz, 5880MHz, 5665MHz, 5645MHz, 5885MHz, 5665MHz, 5645MHz, 5885MHz,
5905MHz, 5925MHz, 5945MHz, 5865MHz, 5785MHz, 5765MHz, 5745MHz, 5725MHz
FRD: 5658MHz, 5695MHz, 5732MHz, 5769MHz, 5806MHz, 5843MHz, 5880MHz, 5917MHz
FRE: 5733MHz, 5752MHz, 5771MHz, 5790MHz, 5809MHz, 5828MHz, 5847MHz, 5866MHz
